Hollyland Mars 400S Pro - SDI/HDMI Wireless Video Transmission System (used)

  • R 11,999.00
    Unit price per
Tax included. Shipping calculated at checkout.


Condition: Fairly used, still very clean

Warranty: 6 months

Hollyland Mars 400S PRO SDI/HDMI Wireless Video Transmission System

Add up to 1080p60 wireless video transmission to your gimbal, mirrorless, or DSLR camera rig using the lightweight Mars 400S PRO SDI/HDMI Wireless Video Transmission System from Hollyland. The transmitter provides HDMI and SDI inputs and the receiver offers SDI and HDMI outputs. It features extremely low 0.1s latency with line-of-sight transmission up to 400' to the receiver and up to 300' to the Hollyview Wi-Fi app. For a strong line-of-sight signal, the system includes two external antennas on the transmitter and two on the receiver, and one is included as a spare.

Using the Hollyview app for iOS or Android, you can monitor your video transmission in real time via a Wi-Fi connection as well as live stream directly from the receiver via your computer using a USB Type-C adapter. The app also allows you to install optional channel scanning firmware enabling you to easily find the strongest transmission signals. The transmitter can simultaneously transmit to up to one receiver and two apps, or to a total of four apps without the receiver. The redesigned body makes it a low-profile choice for your rig, and it features multiple fan modes to keep it cool or quiet when you are shooting.

The 400S PRO transmitter and receiver are compact in size, feature a bright OLED display for configuration, and an integrated shoe adapter with a 1/4"-20 mounting thread for different mounting options. Each unit can be powered using a USB Type-C source, the included locking DC power adapter, or by using a separately available L-series type battery using the integrated battery plate.



Key Features
  • Transmits up to 1080p60 SDI or HDMI video
  • 400' line-of-sight transmission to receiver, 300' to App
  • Bright OLED display
  • Real-time app monitoring and live streaming via the HollyView app
  • Simultaneously transmit to one receiver and two apps, or to four apps
  • HDMI and SDI inputs on transmitter and HDMI and SDI outputs on receiver
  • Two antennas on transmitter and two antennas on receiver
  • Power via L-series battery, DC adapter, or USB Type-C input
  • Integrated shoe adapter with 1/4"-20 mounting thread
  • Install optional channel scan firmware via the HollyView app to find the strongest signal



Specifications
Wireless
Wireless Range
400' / 121.92 m (Line-of-Sight)
300' / 91.4 m (Line-of-Sight)
Channel Bandwidth
20 MHz
Frequency Range
US: 5 GHz
Latency
0.1 sec
RF Power
< 21 dBm
RF Sensitivity
-80 dBm

Transmitter Antenna Ports
2x RP-SMA Male
Receiver Antenna I/O
2x RP-SMA Male
Transmitter Video Connectors
1x BNC (3G-SDI / HD-SDI) Input
1x HDMI Input
Receiver Video Connectors
1x BNC (3G-SDI) Output
1x HDMI Output
Transmitter Other I/O
1x USB-C
Receiver Other I/O
1x USB-C
Embedded Audio
HDMI/SDI

Video Format
SDI/BNC:
1080p at 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps
1080i at 50, 59.94, 60 fps
1080PsF at 23.98, 24, 25 fps
720p at 50, 59.94, 60 fps
HDMI:
1080p at 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps
1080i at 50, 59.94, 60 fps
720p at 50, 59.94, 60 fps
576p at 50 fps
480p at 60 fps

Included
Transmitter Panel Type
OLED
Receiver Panel Type
OLED

Transmitter Battery
2  L-Series / NP-f550 battery
4 antenna
battery charger
